Introduction

Visiyon AI is a self-hosted AI assistant platform. It runs on your own hardware, keeps your data on your own infrastructure, and gives every user in your organization a private, branded chat interface backed by local language models.

What Visiyon AI is

Visiyon AI is a full-stack chat platform: a Next.js frontend, a Fastify API, a Postgres database with pgvector for retrieval, and Ollama for running open models. Everything ships as a single Docker Compose stack, fronted by Nginx.

It is built for teams who want the experience of a hosted assistant — chat history, document upload, voice, web search, tool calling, image generation — without sending data to a third-party API.

Core stack

Requirements

Visiyon AI runs anywhere Docker runs, but it is built and tested against a specific baseline:

• OS: Ubuntu Server 22.04 (any Linux host with Docker also works)
• Docker: Docker Engine + the Compose plugin
• RAM: 8 GB+ recommended to run 8–9B parameter models on CPU
• GPU (optional but recommended): an NVIDIA GPU with nvidia-container-toolkit installed makes inference, transcription, and image generation dramatically faster

None of the above is a hard requirement to boot the stack — it will run CPU-only — but model responses and TTS/STT will be noticeably slower without a GPU.

Installation

1. Install Docker

curl -fsSL https://get.docker.com | sh
sudo usermod -aG docker $USER
newgrp docker

2. Get the project onto your server

scp -r visiyon-ai your-user@your-server:/opt/visiyon-ai
ssh your-user@your-server
cd /opt/visiyon-ai

3. Configure environment

cp .env.example .env
nano .env   # set POSTGRES_PASSWORD and JWT_SECRET to real random values

Generate a strong secret quickly with:

openssl rand -hex 32

4. Build and start everything

docker compose up -d --build

This starts, in dependency order: Postgres, Redis, Ollama, the backend (which pushes the Prisma schema to Postgres on boot), the frontend, and Nginx on port 80.

Check that everything is healthy:

docker compose ps
docker compose logs -f backend

5. Pull models

docker exec -it visiyon-ollama ollama pull glm4:9b
docker exec -it visiyon-ollama ollama pull granite4:8b
# add any others: llama3.1, qwen2.5, gemma2, deepseek-r1, mistral, phi3, llava (vision)

# Required for RAG (document upload / vector search):
docker exec -it visiyon-ollama ollama pull nomic-embed-text

Pulled models appear in the chat model dropdown automatically — no restart needed.

6. Open it

Visit your server's IP or domain. Register an account — the first account created becomes an admin automatically. The admin panel lives at /admin.

Configuration reference

All configuration lives in .env at the project root. Copy .env.example to .env and fill it in.

Required

Ollama

SSO / OIDC

Leave these blank to configure SSO from Admin → Settings → Login providers instead (recommended — persists in the database, no redeploy needed):

Other optional variables

Local development

You can run the backend and frontend outside Docker for faster iteration. You'll still need Postgres, Redis and Ollama reachable (locally or remote).

Backend

cd backend
npm install
npx prisma generate
DATABASE_URL=postgresql://visiyon:visiyon@localhost:5432/visiyon \
REDIS_URL=redis://localhost:6379 \
OLLAMA_URL=http://localhost:11434 \
JWT_SECRET=dev_secret \
npm run dev

Frontend

cd frontend
npm install
NEXT_PUBLIC_API_URL=http://localhost:4000 npm run dev

Project structure

visiyon-ai/
├── docker-compose.yml
├── .env.example
├── nginx/nginx.conf
├── backend/            # Fastify API: auth, chats, models, admin
│   ├── prisma/schema.prisma
│   └── src/
└── frontend/           # Next.js 15 App Router
    ├── app/             # landing page, /chat, /login, /register, /admin
    ├── components/
    └── lib/             # API client + zustand chat store

Accounts & sessions

Visiyon AI uses JWT-based sessions. Anyone can register unless registration is restricted at the network level; the very first account ever created becomes an admin automatically — every account after that is a regular user until an admin promotes them.

• Session tokens expire after JWT_EXPIRES_IN (default 7 days)
• The frontend auto-logs-out and redirects to /login on a 401
• Login, register, and password-reset-request are rate-limited (5–10 attempts / 15 min) to slow down brute-forcing

Password reset

Password reset sends a real email via SMTP (nodemailer — works with any SMTP server, including free local ones like Mailpit). If SMTP isn't configured, the reset token is returned directly in the API response instead, so the flow still works end-to-end in local development.

API keys

Users can issue and revoke personal API keys from Settings. A vis_-prefixed key can be sent as a Bearer token on any route, exactly like a JWT.

Sign in with Microsoft (SSO / OIDC)

Visiyon AI supports an optional “Continue with <provider>” button against any standard OpenID Connect provider — Keycloak, Authentik, Auth0, Azure AD / Microsoft Entra ID, Google Workspace, Okta, and others. The button is automatically hidden when no provider is configured.

When the configured provider name starts with Microsoft or Azure, the login screen automatically renders a branded white “Continue with Microsoft” button with the four-color Microsoft logo. Any other provider name falls back to a plain outlined button.

Configuring Microsoft Entra ID

Fill these in from Admin → Settings → Login providers (recommended) or as OIDC_* environment variables:

Issuer URL:      https://login.microsoftonline.com/<tenant-id>/v2.0
Client ID:       <app registration client id>
Client secret:   <app registration client secret>
Provider name:   Microsoft
Redirect URI:    https://<your-webui-url>/api/auth/sso/callback

1. Create an app registration under Azure Portal → App registrations
2. Add the redirect URI above as a Web platform callback
3. Grant the openid, email, and profile delegated permissions

Permission groups

Admins can create groups with an allowlist of Ollama models and assign users to them. A user with no group — or a group with an empty allowlist — keeps unrestricted access to every installed model.

Use this to, for example, give a finance team access only to a specific compliance-approved model, while engineering keeps access to everything.

Chatting

The core chat experience streams token-by-token over Server-Sent Events, proxied through Nginx with buffering disabled so responses appear live as the model generates them.

Model detection

Every model pulled into Ollama is detected automatically — GLM-4, Granite, Llama, Qwen, Gemma, DeepSeek, Mistral, Phi, and vision models — with no hardcoding required on the Visiyon side. Pull a model with ollama pull and it appears in the dropdown.

Rendering

Replies render Markdown, syntax-highlighted code blocks with a copy button, Mermaid diagrams, and LaTeX via KaTeX.

Folders & organization

Create, rename, and delete folders from the sidebar. Move any chat into or out of a folder from that chat's hover menu. Deleting a folder keeps its chats — they're simply unfiled, never deleted.

Prompt library

Save reusable system-prompt presets. Presets can be personal, or — for admins — shared with everyone on the platform. Apply a preset to a chat in one click; it persists on that chat going forward.

Playground

A standalone page for testing any installed model with free sliders for temperature, top-p, and context window — independent of chat history. Nothing typed or generated in the Playground is saved server-side.

Sharing a chat

Generate a public, read-only link for any chat at /share/:id. Anyone with the link can view the conversation without an account. Revoke the link at any time to cut off access immediately.

Document chat (RAG)

Attach a PDF, DOCX, TXT, MD, or CSV file to any chat and the model will answer using its contents, with clickable source citations.

How it works

1. Click the paperclip icon in the message box and upload a document
2. The backend extracts the text, splits it into roughly 1,200-character overlapping chunks, embeds each chunk with nomic-embed-text, and stores the vectors in Postgres via pgvector
3. Status moves PENDING → PROCESSING → READY (or FAILED with a reason) — the panel polls and updates live
4. Click Attach on a ready document to link it to the current chat
5. From then on, every message in that chat first retrieves the 5 most relevant chunks (cosine similarity) and feeds them to the model as context automatically

Documents live in your personal library and can be attached to multiple chats. Deleting a document removes its chunks and detaches it everywhere it was attached.

Web search

Toggle live web search per message, backed by a bundled SearXNG instance.

1. Click the globe icon in the message box to enable web search for your next message
2. On send, the backend queries SearXNG for your message text and pulls back the top 5 results
3. Results are formatted as a numbered source list and injected as a system message ahead of the conversation — the model is asked to answer using them and cite [n] where relevant

Web search is off by default and only applies per-message. If SearXNG is unreachable, the request still succeeds — it just skips the search context and answers from the model's own knowledge.

Speech in and out

Speak your message using self-hosted Whisper transcription, and hear replies read back with real-time streaming text-to-speech that starts talking while the reply is still generating — and can be interrupted mid-sentence (barge-in).

TTS engines

Pick the engine from Admin → Settings → Voice:

Tools / function calling

Attach tools to a chat and the model can call them mid-conversation, in a multi-round loop — call a tool, get the result, answer — bounded to avoid infinite loops.

Built-in tools

• calculator — powered by mathjs
• current_datetime

Custom HTTP tools

Admins can register additional HTTP tools against any external API, with parameter validation before the call goes out.

Tool calls and their results are persisted as TOOL messages and shown in the UI with a “Used <tool>” indicator.

Image generation

Optional, multi-provider, configured from Admin → Settings → Image generation. Off by default and hidden entirely until configured. Generated images drop into chat history like any other reply.

Running the self-hosted stack

docker compose --profile selfhosted-images up -d sd-webui sd-wrapper

First boot downloads a base Stable Diffusion checkpoint into the sd_models_data volume, which can take a while. Once sd-webui is healthy, set the provider to Self-hosted in the admin panel — the wrapper URL defaults to http://sd-wrapper:8000 in-cluster, nothing else to configure.

Optional env vars: SD_MODEL (force a specific checkpoint filename) and WRAPPER_API_KEY (require a bearer token on the wrapper's own endpoint — useful if you expose it beyond the internal network).

Pipelines (moderation)

Admin-defined keyword/regex rules that run on every message:

• PRE rules can block a message before it reaches the model
• POST rules flag the reply for review

No external moderation API is required — everything runs against your own rule set.

Admin dashboard

Reachable at /admin for any admin account. Covers:

• User list and role management
• Group management with per-group model access
• Server / Ollama / SearXNG health
• Model list, with pull/delete via the API
• Event log

Event log

A database-backed log of authentication failures, SSO errors, tool/document processing failures, and pipeline blocks or flags — filterable by level and source directly in the admin panel.

Analytics

A monitoring tab in the admin panel covering:

• Messages and token usage (prompt/completion, straight from Ollama) over a 7/30/90-day window
• A per-day usage chart
• A per-model breakdown, with an optional cost estimate — configure MODEL_COST_PER_1M to attach a reference $/1M-token figure. Self-hosted Ollama has no real per-token cost, so this is opt-in and for reference only
• A per-user table: messages, tokens, and last active time

Built-in support chat

A “Need help?” widget in the bottom-right corner of any logged-in page, answering questions about how to use Visiyon itself — where a setting lives, what a feature does, why a model isn't showing up.

It runs on the deployment's own local Ollama — no external API, no extra cost — and picks whichever chat-capable model is already installed unless SUPPORT_MODEL is set.

Updating

Manual (always works)

git pull   # or copy new files over
docker compose up -d --build

From the admin panel

Admin → Updates can check for new releases and apply them with one click, so people running a fork of the platform don't need shell access to stay current.

• It compares the running APP_VERSION against the latest GitHub release of the repo set in UPDATE_REPO (e.g. UPDATE_REPO=yourname/your-fork in .env). Leave it unset and the Updates page just reports that updates aren't configured — nothing else changes
• Applying an update is handled by a small updater sidecar container that has the host's Docker socket and the repo checkout mounted in. It runs git fetch + git reset --hard origin/<branch> + docker compose up -d --build, streaming progress back to the admin panel. UPDATE_BRANCH controls which branch it pulls (default main)
• Only that sidecar gets Docker/host access — the main backend never does. To disable self-service updates entirely, comment the updater service out of docker-compose.yml and leave UPDATE_REPO unset

Bump APP_VERSION in your environment each time you cut a new release, so the version shown in the sidebar and the update check stay accurate.

Enabling GPU stats

The Admin → System resources panel needs the GPU attached to the backend container specifically — by default it's only attached to Ollama/sd-webui. If the backend runs on the same GPU box:

docker compose -f docker-compose.yml -f docker-compose.gpu.yml up -d --build

Troubleshooting, in order

1. Confirm the host sees the GPU

nvidia-smi -L

If this fails, install/configure the NVIDIA driver on the host before anything below will work.

2. Confirm GPU passthrough into Docker works at all

docker run --rm --gpus all nvidia/cuda:12.4.1-base-ubuntu22.04 nvidia-smi

If this fails, the host's NVIDIA Container Toolkit isn't wired up to the Docker daemon yet:

sudo nvidia-ctk runtime configure --runtime=docker
sudo systemctl restart docker

3. Confirm the GPU override actually reaches the backend service

docker compose -f docker-compose.yml -f docker-compose.gpu.yml config | grep -B2 -A8 "runtime\|reservations"

You should see both a runtime: nvidia line and a deploy.resources.reservations.devices block under backend. If you see neither, re-copy docker-compose.gpu.yml from the repo and retry.

4. "executable file not found in $PATH" inside the container

This is almost always the backend's base image, not the GPU passthrough itself. The NVIDIA Container Toolkit injects nvidia-smi and driver libraries in a way built against glibc — it does not reliably work on musl-based images like node:*-alpine. This project's backend/Dockerfile uses node:20-bookworm-slim (Debian, glibc) specifically for this reason.

If the Dockerfile has been customized to an Alpine base, GPU stats will not work regardless of compose configuration — switch back to a Debian/Ubuntu-based Node image and rebuild without cache:

docker compose -f docker-compose.yml -f docker-compose.gpu.yml build --no-cache backend
docker compose -f docker-compose.yml -f docker-compose.gpu.yml up -d backend
docker exec -it visiyon-backend nvidia-smi

Once nvidia-smi works inside the container, the admin panel picks it up automatically on its next poll — no further restart needed.

FAQ

Does any user data leave my server?

No, by default. All inference runs against your own Ollama instance. Data only leaves your infrastructure if you deliberately configure a cloud provider — ElevenLabs for voice, or OpenAI/Stability AI for image generation.

Can I run this without a GPU?

Yes. Everything runs CPU-only; expect slower model responses, transcription, and image generation.

What happens if I don't configure image generation or SSO?

Both are hidden entirely from the UI until configured — nothing broken or half-visible.

Where do I report a bug or request a feature?

Use the Visiyon Community forum.
